Brown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryer

Packaging:
Wooden case (fumigation free) or as per customers' requirements
Supply Ability:
100 Set/Sets per Year
Port:
Shanghai Port ,China

Product Description

Spray dryerBrown powder LPG model high speed Centrifugal spray drying machine stevia sugar stevia extract dryerWorking Principle:The air is filtered and heated into the top of the dryer air distributor, hot air into the spiral evenly into the drying chamber. The material liquid is sprayed into a fine atomized liquid droplet through the high-speed centrifugal nebulizer at the top of the tower body, and can be contacted with the hot air in a very short time and can be dried into finished products. The finished product is continuously discharged from the bottom of the drying tower and the cyclone, and the exhaust gas is drained by the draft fan.Brown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryer
ModelWKS-SD-5WKS-SD-25WKS-SD-50WKS-SD-150WKS-SD-200~2000
Item / Parameters
Inlet temperature100-350100-350100-350100-350100-350
Outlet temperature50-9050-9050-9050-9050-90
Maximum evaporation of water (kg / h)52550150200~2000
Maximum speed (r.p.m)250001800018000150008000~15000
Spray disc diameter (mm)50120120150180~240
Heat sourceelectricity, steam, gas, etc. (as per customers' requirements)
Electric heating maximum power (kw)9367299150
Dimensions (L × W × H) (m)1.8×0.93×2.23×2.7×4.263.5×3.5×4.85.5×4×7based on actual conditions
Dry powder recovery (%)≥95≥95≥95≥95≥95
Product FeaturesHigh speed drying:the surface area of liquid material is greatly increased  after atomization, achieving instantaneous evaporation of 95% -98% water in the hot air flow, drying time only takes a few seconds, especially for heat-sensitive materialsProducts achieve good uniformity, mobility and solubility, and also achieve purity, good quality. The production process is simplified and the operation control is convenient. For liquid materials with the moisture content of 40-60% (special materials up to 90%) can be dried into powder products just with one time, do not need grinding and screening after drying, reduce production processes and improve product purity. The product size, bulk density, moisture, in a certain range can be adjusted by changing operating conditions, control and management are very convenient.The air is filtered and heated into the top air distributor of the dryer, and the hot air enters the drying chamber evenly in a spiral fashion. The material liquid is sprayed into a fine atomized liquid droplet through the high-speed centrifugal nebulizer at the top of the tower body, and can be contacted with the hot air in a very short time and can be dried into finished products. The finished product is continuously discharged from the bottom of the drying tower and the cyclone, and the exhaust gas is drained by the draft fan.Brown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerApplication
Food and plants: oats, chicken juice, coffee, instant tea, seasoning spices meat, protein, soybeans, peanut protein, hydrolysates and so on.Carbohydrates: corn steep liquor, corn starch, glucose, pectin, maltose, potassium sorbate and the like. Chemical industry: battery raw materials, basic dye pigments, dye intermediates, fertilizer, formaldehyde silicic acid, catalysts, agents, amino acids, silica and so on.Ceramics: alumina, ceramic tile materials, magnesium oxide, talcum powder and so onBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryerPackaging & Shipping Packaging: wooden case (fumigation free) or as per customers' requirementsShipping: within 5 to 7 working days after receiving the balance payment Brown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryer Our ServicesBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryer Company InformationBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryer FAQBrown powder LPG model high speed centrifugal spray drying machine stevia sugar stevia extract dryer
